Used 660 x 20 mm ERW API Mill include 2200X20 Slitting Line

Used ERW API MILL SLITTING LINE

1. Background

The φ660×20 mm ERW Tube Mill Line is designed to produce ERW tubes of size φ273 – φ660 mm, and thickness of 5 – 22 mm. It was made in 2011 and quit production in 2015.

2. Overview

  • Year of manufacture: 2011
  • Quit production: 2015
  • Location: China
  • Reason of stop: Marketing issue
  • Inline: Yes
  • Work condition: Great condition; complete; nice and easy for starting a factory.

3. Specifications:

Coil Specification

  • Sheet thickness: 5-20 mm
  • Sheet width: 618-2100 mm
  • Coil I.D.: f760 mm
  • Coil O.D.: f1500-f2300 mm
  • Coil weight: Max. 35 tons
  • Steel grade: Max J55, K55, X80

4. Product specification

  • Rounds: f273-f660 mm
  • Thickness: 5-22 mm
  • Length: 11.5-12 m

5. Equipment List

  • 1 - Coil car & prep table
  • 1 - Uncoiler
  • 1 - Peeler
  • 1 - Pinching roller
  • 1 - 5-roll leveler
  • 1 - Transit roller table
  • 1 - Cut end & welder
  • 1 - Pinch roller
  • 1 - 7-roll leveler
  • 1 - Spiral accumulator with in/out twist stands
  • 1 - Pinch roll
  • 1 - Forming stands (Spindle: f320 mm)
  • 1 - Welder box
  • 1 - 1800 KW Welder (Solid state HF welder)
  • 2 - Bead trimmer with scrap rewinder
  • 4 - Seam Annealer (4 × 600 KW IF induction seam annealer)
  • 1 - Air cooling racks
  • 1 - Water cooling trough
  • 1 - Sizing stands
  • 1 - In line seam UT
  • 1 - Turks Head (Two stands)
  • 1 - Flying cut-off saw
  • 1 - Run-out racks
  • 1 - End facing and beveller
  • 1 - Hydrostatic tester
  • 1 - Transit conveyors
  • 1 - 2200 × 20 mm Slitting Line
